SD 45.25" Long 1.65" Diameter Pole With One Display Head Mount 115
Mfr # SD-DP-1150
The Atdec Donut Poles offer superior display versatility. They come in three different lengths each including one QuickShift™ Donut to guarantee a customized display installation. The cutting-edge QuickShift™ lever allows the screen to be moved up and down the pole by hand, without the need for any tools. Viewing angle and screen orientation are also fully adjustable thanks to the ball joint mechanism, finished off with a quick release mechanism to rapidly remove and change screens. Built in internal cable management ensures a professional finish for maximum display impact.
• Ideal solution for any retail/point of sale environment
• Includes one QuickShift™ donut to support one display
• Tool-less QuickShift™ lever for easy display position adjustment
• Quick release mechanism for easy monitor attachment/removal
• Bolt through and Desk clamp desk fixing options included
• All mounting hardware included
• Available in two other lengths to support two or three monitors (SD-DP-420 or SD-DP-750)
• Upgrade plate for 200x100 & 200x200 VESA available (on request)
• 10 year warranty
Specifications
Product code: SD-DP-1150
Upgradable to carry additional display: Yes
Material: Steel
Color Options: Black
Warranty: 10 years
Desk fixing options: Bolt through and desk clamp options included
Compatibility
Minimum display weight,: lb 0.00
Flat screen: maximum supported weight,: lb 26.50
VESA mounting hole pattern: 75x75, 100x100
Minimum desk thickness: 0.5
Maximum desk thickness allowed (inches): 1.5
Range Of Movement
Spring assisted height adjustability: No
Rotation around pole: No
Tilt adjustment: 20° in any direction
Pan adjustment: 20° in any direction
Landscape to portrait screen rotation: Yes
Height adjustable: Yes
Maximum arm reach (inches): 4.37
Packaging Dimensions
Length, single unit (inches): 46.5
Width, single unit (inches): 9
Height, single box (inches): 5.5
Weight, master carton,: lb 20.80
Weight, single unit,: lb 4.20
Single units per master pack: 2
Length, master carton (inches): 47.25
Width, master carton (inches): 10.25
Height, master carton (inches): 12
