ViewSonic CDE5530 Wireless Presentation Display - 55" LCD - ARM Cortex A55 1.50 GHz - 4 GB DDR4 SDRAM - 3840 x 2160 - Direct LED - 450 Nit - 2160p - HDMI - USB - Serial - Wireless LAN - Bluetooth - Ethernet - Android 11 - Black
Mfr # CDE5530
*Terms & Conditions = Pricing and availability are subject to change. No returns or refunds for ViewSonic products.*
Multiple Ways To Connect And Share
Connect wirelessly through your network or directly to the display. Use the ViewBoard Cast™ screen sharing software along with the web-based myViewBoard® Display app to allow up to four participants (on-site and remote) to connect and share their content regardless of what OS platform they are using (Windows, MacOS, Chrome OS, Android, iOS). In addition, AirPlay, Miracast and the optional ViewBoard Cast button all offer wireless and software-less casting options.
AV Control System Interoperability
These displays are Crestron Connected® as well as Extron and AMX certified for seamless integration. Network admins are always in control with the ability to send control signals such as on/off, switch inputs, push firmware and security updates, and get status from the display.
Centralized Device Control Manager
For IT admins, it's tough managing the hundreds of devices and displays that live on the network. Now with myViewBoard Manager, an easy-to-use web-based application, IT can securely set up, manage and maintain all of the displays from a centralized dashboard.
Reliable 24/7 Operation Rating
Featuring a long lifespan, this professional-grade commercial display is designed for reliable use 24 hours a day, 7 days a week. Ideal in virtually any commercial application and environment, this commercial display delivers peace of mind with its robust and durable design.
Superb And Stunning Picture Quality
With 4K resolution, high brightness and 25% high haze anti-glare glass treatment, these displays deliver bright, clear and sharp images in any indoor environment.
Powerful Secured Embedded Platform
This display can execute several tasks at once while providing smooth content playback without the need for a PC or media player. The embedded SoC provides PC-like performance and power to run apps, while hardened custom Android OS firmware protects the display from viruses and security breaches by preventing unknown sources to be installed on the system.
Flexible Installation
With landscape or portrait mode options, a uniform bezel width, HDMI in and HDMI out for up to 9-screen tiling (ex 1x2, 2x2, 3x2, 4x2, 3x3, 1x9, etc.) without an external HDMI matrix, this display delivers versatile video wall configuration out-of-the-box.
Advanced Multi-Source Capability
Picture in Picture (PiP) and Picture by Picture (PBP) options allow up to two independent sources to run at the same time.
Main Features
Manufacturer: ViewSonic Corporation
Manufacturer Part Number: CDE5530
Manufacturer Website Address: www.viewsonic.com
Brand Name: ViewSonic
Product Series: CDE30
Product Model: CDE5530
Product Name: CDE5530 Wireless Presentation Display
Package Type: Retail
Product Type: Digital Signage Display
Display & Graphics
Number of Screens: 1
Screen Size: 55"
Display Screen Type: LCD
Touchscreen: No
Display Resolution: 3840 x 2160
Backlight Technology: Direct LED
Graphics Controller Manufacturer: ARM
Graphics Controller Model: G52MP2
Interfaces/Ports
USB: Yes
HDMI: Yes
DisplayPort: Yes
Serial: Yes
Number of USB 2.0 Ports: 1
Number of USB 3.0 Ports: 1
Number of HDMI Inputs: 3
Number of HDMI Outputs: 1
Number of DisplayPorts: 1
USB Type-C: Yes
Memory
Standard Memory: 4 GB
Memory Technology: DDR4 SDRAM
Miscellaneous
Package Contents:
• CDE5530 Wireless Presentation Display
• Power cable (3 metres)
• Remote Control
• Batteries
• Quick Start Guide
• HDMI cable (3 metres)
• USB-C cable (1.8 metres)
• Wall Mount Screw (M8 x 4)
• RS232 adaptor
Energy Star: Yes
Environmentally Friendly: Yes
Environmental Certification: ENERGY STAR 8.0
Environmental Certification: ErP
Environmental Certification: RoHS
Environmental Certification: REACH
Environmental Certification: WEEE
Network & Communication
Ethernet: Yes
Wireless LAN: Yes
Bluetooth: Yes
Physical Characteristics
Product Color: Black
VESA Mount Standard: 400 x 200
Mount Type: Wall Mountable
Height: 37.9"
Width: 66.4"
Depth: 3.2"
Weight (Approximate): 29.54 lb
Power Description
Input Voltage: 120 V AC
Input Voltage: 230 V AC
Processor & Chipset
Processor Manufacturer: ARM
Processor Type: Cortex A55
Processor Speed: 1.50 GHz
Processor Core: Quad-core (4 Core)
Software
Operating System: Android 11
Technical Information
Bezel Width: 0.59"
Panel Technology: Advanced Super Dimension Switch ( ADS )
Operation Hours: 24 Hours/7 Days
Video
Scan Format: 2160p
Dynamic Contrast Ratio: 5,000:1
Color Depth: 8-bit+FRC
Brightness: 450 Nit
Warranty
Limited Warranty: 3 Year
